Tempered Energy Efficient Glass Heat Sound Insulation Bump Resistance

China Tempered Energy Efficient Glass Heat Sound Insulation Bump Resistance supplier
Tempered Energy Efficient Glass Heat Sound Insulation Bump Resistance supplier Tempered Energy Efficient Glass Heat Sound Insulation Bump Resistance supplier

Large Image :  Tempered Energy Efficient Glass Heat Sound Insulation Bump Resistance

Product Details:

Place of Origin: CHANGSHU CHINA
Brand Name: SYSEN
Certification: IGCC IGMA

Payment & Shipping Terms:

Minimum Order Quantity: 1 PIECE
Price: negotiable
Packaging Details: strong sea worthy wooden creates with paper interleaved
Delivery Time: 25 DAYS
Payment Terms: L/C, T/T
Supply Ability: 100000 PIECEC MONTH
Contact Now
Detailed Product Description
According To The Customer Requirements: According To The Customer Requirements Specification: According To The Customer Requirements
Color: Clear,grey,green,blue,bronze Quality Grade: Construction Use, Furniture Use And So On
Type: Float Glass Technique: Clear Glass,Tempered Glass,Tinted Glass
High Light:

Energy Saving Glass

,

Thermally Efficient Glass

Popular fashion energy efficient low emissivity glass lose weight agon filled



The insulated glass is widely used in glass curtain walls, doors, windows and place with glass in automobile

Insulated glass is also called hollow glass. Insulating glass is made of two or more pieces of glass with the middle part separated by the hollow AL tube which is filled with the drier. The hollow part is filled with dry air or inert gas and sealed by butyl glue, sulfur glue or structural sealant.

Performance Features of insulating glass:


1. The insulating glass filled with the inert gas is excellent in heat and sound insulation, meeting the requirement for saving energy and environmental protection.
2. Hoarfrost and dew effect can be eliminated.
3. High wind pressure strength of the hollow glass.
4. Not easy to be self exploded.
5. When choosing coated glass as the basal pieces, the coated layer will not come off.



Advantages:



A. Modern style, unique

B. Heat resistance, notice resistance, keeping warm

C. Oxygenation resistance, bump resisitance

D. Bear high & low temperature



Tempered Energy Efficient Glass Heat Sound Insulation Bump Resistance

Sealing performance: Quickly formed by using aluminum frame once. The use of double sealing-butyl rubber and structural adhesive or polysulfide rubber ensures good sealing performance and longer service life of hollow glass.

Applicable Range

The insulated glass is widely used in glass curtain walls, doors, windows and place with glass in automobile, ships, aircrafts and instruments.

Optical performance: Flexible to choose different light transmission and reflectivity.

Heat conductivity: Lower U-factor and more effective with inert gases



Ultimate Dewpoint



SYSEN effectively eliminates dew condensation between glass layers.
Dew condensation is caused by the temperature difference between the inner and outer surfaces of insulated glass. The high vacuum interspace of LandVac effectively eliminates the dew condensation phenomenon, while the outstanding thermal insulation performance ensures interior glass surface free of condensation even when the outdoor temperature falls to -40 °C.



Product details:

Product Name Low-e Insulating Glass
Thickness 5+6A+5~15+15A+15
Size Minimum Size 250mm×350mm
Maximum Size 2540mm×4500mm
Color Clear, Blue, Green, Dark brown, etc.
Type of Sheet Glass Float glass, Tinted glass, Coated glass, etc.
Aluminum Strip Width 6 mm,9 mm,12 mm,15mm, etc.
Insulating Gas Argon
Packing Details

(1)Interlay paper or plastic between two sheets;

(2)Seaworthy wooden crates;

(3) Iron belt for consolidation.

Quality Standard CE ,ISO9001,CCC
Application

(1)Facades and curtain walls

(2)Skylights

(3)Green house

Types Low-e insulated glass,Insulated tempered glass,Insulated tempered glass,Insulated laminated glass,Coated insulated glass,Colored insulated glass,Curved insulated glass.
Note: can be customized according to the given specifications and colors from clients.
