Clear Tempered Glass Panels , 3.2 / 5 / 6 / 8 / 10 / 12 Mm Tempered Glass Pane

Certification
Good quality Wrought Iron Glass for sales
Good quality Wrought Iron Glass for sales
Customer Reviews
you are a honest supplier, we are very happy to work with U

—— Louis

The quality is very good and worth relying on

—— Amy

I'm Online Chat Now

Clear Tempered Glass Panels , 3.2 / 5 / 6 / 8 / 10 / 12 Mm Tempered Glass Pane

China Clear Tempered Glass Panels , 3.2 / 5 / 6 / 8 / 10 / 12 Mm Tempered Glass Pane supplier
Clear Tempered Glass Panels , 3.2 / 5 / 6 / 8 / 10 / 12 Mm Tempered Glass Pane supplier Clear Tempered Glass Panels , 3.2 / 5 / 6 / 8 / 10 / 12 Mm Tempered Glass Pane supplier

Large Image :  Clear Tempered Glass Panels , 3.2 / 5 / 6 / 8 / 10 / 12 Mm Tempered Glass Pane

Product Details:

Place of Origin: CHANGSHU CHINA
Brand Name: SYSEN
Certification: IGCC IGMA

Payment & Shipping Terms:

Minimum Order Quantity: 1 PIECE
Price: negotiable
Packaging Details: plywood packing
Delivery Time: 25 DAYS
Payment Terms: L/C, T/T
Supply Ability: 10000 PIECE MONTH
Contact Now
Detailed Product Description
Production Range: Low-E Glass,tempered Glass, Insulated Size: Custom Design Availble
Packing: Wooden Cases Sample: Available
Application: Building Structure: Hollow
Type:: Float Glass

clear beveled tempered glass 3.2MM,5MM,6MM,8MM,10MM,12MM artist easy clean


Description of tempered glass


Tempered glass is a type of glass with evenly distributed compressive stresses on the surface which is made by heating float glass to nearly softening point and then cooling it down rapidly by air. During the instant cooling process, the glass exterior is solidified due to rapid cooling while the interior of glass is cooled down relatively slowly. This process will improve the glass exterior compressive stress and interior tensile stress resistance which can improve the overall mechanical strength of glass by gemination and result in good thermal stability.


Advantages of tempered glass


1> Tempered glass is 5 times harder than ordinary float glass
2> Tempered glass is with Excellent mechanical strength and safety performance
3> High security, once tempered glass breakage occurs, the glass disintegrate into small cubical fragments,which are relative harmless to human body
4> Sizes of tempered glass are produced per customer request, once tempered, cannot be cut down


Clear Tempered Glass Panels , 3.2 / 5 / 6 / 8 / 10 / 12 Mm Tempered Glass Pane

Glass Material clear float glass, ultra clear float glass(low iron glass), low-e glass, frosted glass(acid etched glass), sandblasting glass, bronze glass, grey glass, patterned glass, borosilicate glass, ceramic glass, coated glass, AR glass, AG glass, etc.
Size according to customer’s requirements
Shape rectangular, round, ellipse, semiellipse, hexagon or other special shape
Edge shape straight, round, beveled, stepped, etc.
Edge work edges arrised, edges ground, edges polished, etc.
Corners blunted corners, round corners or cut corners
Drilling normal holes or counterbore (according to customer’s requirements)
Printing silk-screen printing with black, white, gray, gold, brown, red, yellow, sandblasting effect, etc.(color is RoHS-compliant )
Tempering En60598, En12150, etc.(High security, once tempered glass breakage occurs, the glass could break into small fragments, which are harmless to human body)
Packing plywood crates with paper interlayer which are solid and exquisite
Main Products glass cutting board, range hood glass, refrigerator glass, oven glass, electric fireplace glass, instrument glass, glass light cover, air conditioner glass, washing machine glass, window glass, louver glass, screen glass, etc.



The specifications of tempered glass



Max. size of flat tempered glass:

4-8mm: 2400×3600mm
10-12mm: 2400*4200mm
15-19mm:2400*4500mm

Max. size of bent tempered glass: 4-15mm:2400*1500mm
Radius:

Thickness 4 ~ 6mm R ≥ 480mm
8 ~ 12mm R ≥ 800mm
15mm and above R ≥ 1500mm

Thickness: 4mm, 5mm, 6mm, 8mm, 10mm, 12mm, 15mm,19mm, etc.
Color:

Clear, Ultra clear;
Euro bronze, golden bronze;
Blue, ocean blue, dark blue, light blue;
F green, light green, dark green;
Euro Grey, dark Grey.

Production Range

Low-E glass,tempered glass, insulated glass, laminated glass,
reflective glass etc.

Application

Building Curtain Wall, Windows, Doors, Exhibition Hall,
Shower Room And Furniture Glass

Delivery time 1~2 weeks after received the deposit
