Hollow Low Maintenance Custom Glass Window Panels Effortless Operation

Hollow Low Maintenance Custom Glass Window Panels Effortless Operation

Product Details:

Place of Origin: CHANGSHU CHINA
Brand Name: SYSEN
Certification: IGCC IGMA

Payment & Shipping Terms:

Minimum Order Quantity: 1 PIECE
Price: negotiable
Packaging Details: plywood packing
Delivery Time: 25 DAYS
Payment Terms: L/C, T/T
Supply Ability: 10000 PIECE MONTH
Get Best Price Contact Now

Detail Information

Size: Min. 200x300mm, Max.2440mmx8000mm Size: Custom Design Availble
Edge: Flat,round,beveled Edge Product Name: Bevele Edge Tempered Glass
Application: Building Structure: Hollow
High Light:

Beveled Glass Panels

,

Clear Beveled Glass Panels

Product Description

Hollow Low Maintenance Custom Glass Window Panels Effortless Operation





A patio door is a glass door, half of which is fixed in place. The other half of the sliding glass door slides open over the fixed portion. It is a source of natural light and a great way to access your porch, deck, back yard or pool area.

There are many options to consider when choosing replacement patio doors. The size of your wall area and how much natural light you want to let in will help you determine the best size for your sliding glass door. Standard patio doors are 6 feet, 8 inches tall. Width size varies depending on whether the patio door is a two- or three-panel configuration.

approve, then the glass selection is made and the art glass panel is fabricated by our skilled craftsmen.



Thickness 3mm,4mm,5mm,6mm,8mm,10mm,12mm,15mm,19mm
Color Clear, bronze, grey, green, blue
Size Min. 200x300mm, Max.2440mmx8000mm, custom sizes
Deep proessing Laminated, insulated, acid etched, printed
Applications Windows, doors, curtain wall, balcony, railling, table top
Certificate CE, ISO, CCC, BS6202
Packing Exportation wood box
Delivery time 7-15 days

Hollow Low Maintenance Custom Glass Window Panels Effortless Operation 0

Clean Cut: Clean cut glass has a raw edge, is sharp, and may have small chips on the edges.
Seamed: Seaming produces a sanded edge that is not sharp, has the look of a natural cut, and may have small chips on edge.
Pencil Ground Edge: A machined edge with a smooth, rounded profile. The ground edge has a sanded, nearly white appearance.
Pencil Polished Edge: A machined edge with a polished, rounded profile. The polished edge has a similar appearance to the face of the glass.
Flat Ground Edge: A machined edge with a smooth, flat, and angular ground edge. The ground edge has a sanded, nearly white appearance.
Flat Polished Edge: A machined edge with a polished, flat, and angular profile. The polished edge has a similar appearance to the face of the glass.
Beveled Pencil Edge: Beveled edges are specified by width (½” – 1 ½”) and are created through a grinding and polishing process. The edge is ground to a pencil profile.
Beveled Pencil Polish: Beveled edges are specified by width (½” – 1 ½”) and are created through a grinding and polishing process. The edge is ground and polished to a pencil profile.

Hollow Low Maintenance Custom Glass Window Panels Effortless Operation 1

safety When broken, it spits into tiny harmless pieces.
Strong intensity heat-strengthened glass is approximately twice as strong as annealed glass of thesame
Application Places where safety glass is required by laws and regulations.Windows or other areas in a building.Windows of motor vehicles, boats and ships.
Specification our clear tempered glass Can be produced according to your request.
technical CCC , ICGG ,IGMA

A beveled edge is found on both glass tops, and mirrors hanging on walls with or without frames. Normally when found on a glass top, there is not full support underneath the glass, so the bevel can be seen. Examples being glass pedestals, or coffee tables with the center open.

The glass is sent through a beveling machine with a number of wheels again ranging in grit, getting finer towards the end. And lastly the glass encounters felt wheels along with cerium oxide to polish the bevel back to clear.

Bevels create a very beautiful traditional look that can really bring out the beauty of the glass.
